Product Details:
|
| Product Name: | PBE-5AC-500 | Brand Name: | UBNT |
|---|---|---|---|
| WAN Ports: | 1 | Use: | FTTH |
| Color: | White | Application: | WiFi Bridge |
| Power Method: | 10/100/1000 Ethernet Port | Warranty: | 1 Year |
| High Light: | 5G Gigabit Wireless Bridge,CPE Gigabit Wireless Bridge,20 Kilometers CPE Wireless Bridge |
||
UBNT 5G Gigabit wireless bridge PBE-5AC-500 20 kilometers wifi long-distance transmission wireless monitoring CPE
Description:
PBE-5AC-500
1.The form factor of the PowerBeam™ features the highest gain for its size.
2.The PowerBeam’s excellent beam directivity provides the best performance in high-noise environments.
3.Using airMAX ac technology, the PBE-5AC-500 supports up to 450+ Mbps real TCP/IP throughput.
3.It launches with PtP functionality, and a client mode feature will be added with a future firmware upgrade.
The PBE-5AC-500
1.includes a protective radome to shield the radio from the elements.
2.The PowerBeam™ PBE-5AC-500 includes a protective radome to shield the radio from the elements.
3.The PBE-RAD-400 is an optional accessory available for the PBE-M2-400 and PBE-M5-400.
Specification:
| Physical/Electrical/Environmental | |
| Model | PBE-M5AC-500 |
| Dimensions (mm) | 520 x 520 x 308 |
| Weight | 2.350 kg |
| Power Supply | 24V, 0.5A PoE |
|
Power Method |
Passive PoE (Pairs 4, 5+; 7, 8 Return) |
| Max. PowerConsumption | 8,5 W |
| Gain | 27 dBi |
| Wind Loading | 94,33 lbf @ 125 mph |
| Wind Survivability | 125 mph |
| LEDs | (1) Power, (1) LAN, (4) WLAN |
| Signal StrengthLEDs | Software-Adjustable toCorrespond to Custom RSSILevels |
| Channel Sizes | 5/8/10/20/30/40 MHz |
| Polarization | Dual Linear |
| Enclosure | Outdoor UV Stabilized Plastic |
| Mounting | Pole-Mount Kit Included |
| ESD/EMPProtection | Air: ±24 kV, Contact:± 24 kV |
| OperatingTemperature | -40 to 70° C |
| OperatingHumidity | 5 to 95% Non-Condensing |
| Shock & Vibration | ETSI300-019-1.4 |
| Model |
|
|||
|---|---|---|---|---|
| Frequency | 2.4 GHz | 5 GHz | 5 GHz | 5 GHz |
| Throughput | 330+ Mbps | 450+ Mbps | 450+ Mbps | 450+ Mbps |
| Range | 20+ km | 25+ km | 30+ km | 25+ km |
