Huawei MA5608T OLT Mini GPON OLT Optical Line Terminal

Huawei MA5608T OLT Mini GPON OLT Optical Line Terminal
Huawei MA5608T OLT Mini GPON OLT Optical Line Terminal
Huawei MA5608T OLT Mini GPON OLT Optical Line Terminal Huawei MA5608T OLT Mini GPON OLT Optical Line Terminal Huawei MA5608T OLT Mini GPON OLT Optical Line Terminal Huawei MA5608T OLT Mini GPON OLT Optical Line Terminal Huawei MA5608T OLT Mini GPON OLT Optical Line Terminal

Large Image :  Huawei MA5608T OLT Mini GPON OLT Optical Line Terminal

Product Details:
Place of Origin: Guangdong, China
Brand Name: Huawei
Certification: FCC,CCC,CE
Model Number: Ma5608T
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable

Huawei MA5608T OLT Mini GPON OLT Optical Line Terminal

Description
Product Name: Huawei Name: Ma5608T
Warranty: 1year Dimension: 442mm*244.5mm*88.1mm
Selling Units: Single Item Single Package Size : 59X39X19 Cm
Single Gross Weight: 11.000 Kg Package Type: 1piece 10G GPON OLT MA5608T New And Original In A Box
High Light:

huawei gpon olt

,

mini olt gpon

,

gpon olt device

Huawei MA5608T OLT Mini GPON OLT Optical Line Terminal



Compact and modular design
* 2 RU, 19” rack mounting,12” depth.
I/O Slots:
*
2 slots for service cards, 2 slots for switch and control cards, 1 slot for redundant power input.Switch and control card with uplink ports:* 60 Gbps switch card with integrated 2 port 10GbE and 2 port 1GbE WAN uplinks.
Large capacity in Small Size –
* 200 Gbps backplane
* 20 Gbps/slot capacity

* 120 Gbps load sharing switching capacity

* 2x10 Gbps uplink capacity

Advanced Layer 2 Functions:

* QoS with traffic classification and L2 forwarding policy

* Standard VLAN, QinQ VLAN, VLAN stacking

* Flexible QinQ VLAN tagging

* DHCP Option 82 in L2 mode

* MEF-9 & MEF-14 certification

L3 Functions for maximum deployment flexibility

* ARP, ARP proxy

* DHCP relay, DHCP proxy

* Static routing

* Dynamic routing: RIP, OSPF, ECMP

* Multicast: IGMP v2/v3, IGMP proxy, IGMP snooping

High Reliability

* WAN uplink redundancy: BFD, MSTP, LACP, RSTP, RRPP Fiber redundancy with 50ms switchover

* Carrier Class Availability: Dual switch and control card, dual power input, PON port redundanc

The Huawei OLT GPON MA5600T Series Specifications:

Specifications

Dimensions
MA5600T Chassis (10U): 530mm×275.8mm×447.2 mm
MA5603U Chassis (8U): 352.8mm×305mm×536mm
MA5608T Chassis (2U): 442mm×233.5mm×88.1mm
Power Supply
MA5600T/MA5603U: -48V or -60V DC powering via redundant power feeds, working voltage range: -38.4V to -72V
MA5608T supports both DC/AC power supply mode and supports dual power protection and battery backup while using the AC power; DC: -38.4VDC to -72VDC; AC: 100V to 240V
Running Environment
MA5600T ambient working temperature : -25C to +55C
MA5603U/MA5608T ambient working temperature : -40C to +65C; -40º F to +149º F
GPON Features of MA5608T
• 16 ports per card or 8 ports per card
• Robust Compliance to G.984 Series standards with 2.5/1.2 Gbps downstream and 1.2Gbps line
speed performance
• Support for B+ or C+ optical modules (SFPs) with max 40km differential distance
• Up to 1:128 split ratio per GPON port
• Optical Power Monitoring, Real Time Rogue ONT detection/isolation
XG-PON1 Features of MA5608T
• 4 ports per card
• Fully compatible with GPON - compliance G.987 Series standards with 10/2.5 Gbps line speed
performance
• Supports XFP optical modules
VDSL2+POTS Combo of MA5608T
• 48 VDSL2 and POTS integrated ports with up to 17a profile
• Two-pair bonding for maximum speed
• G.INP (G.998.4) support for re-transmission at the physical layer
• Built-in support for SELT, DELT, and MELT
• POTS line Loop-Start Operation
• Ringing Mode – Balanced ringing with -15VDC offset on “Ring”
• Multiple CODECs – G.711 (µ-Law and A-Law), G.729, G.723, G.726



Huawei MA5608T OLT Mini GPON OLT Optical Line Terminal 0
