Product Details:
|
Wavelength: | 1528-1563nm (C-Band); 1571-1605nm (L-Band) | Product Name: | EDFA Optical Amplifier |
---|---|---|---|
Optical Connector: | SC/APC&SC/PC | Power Supply: | 220VAC |
Noise Figure: | 5.5dB ( Max 6.0) | Input Optical Power: | -3~10 DBm,-5dbm~+10dbm |
High Light: | CATV Optical Amplifier,26dBm EDFA Amplifier,24dBm CATV Amplifier |
1550nm 24dBm 26dBm catv optical amplifier EDFA dual pump and SNMP EDFA
Descriptions
1. 15EAxx EDFA is based on the paragraph 08EAxx improvement model, mainly to solve the external hot backup power supply, users can configure backup power supply according to the power of arbitrary, damaged power supply does not need to open lid can be arbitrary replacement, light box adopts modular structure and convenient maintenance.
2. 15EAxx 1550nm EDFA is an important transmission equipment of 1550nm optical fiber communication system, mainly used for television image signals, digital TV, telephone voice signal and the signal of the data (or compressed data) optical fiber transmission over a long distance.
3. WS-15EAxx series EDFA optical amplifier technical performance indicators of erbium doped fiber amplifier and the technology can be comparable to similar imported models, and cost-effective, easy installation is choice equipment to build large and medium-size of1550nmcatv optical fiber transmission network.
EDFA Feature
♦ 1540~1563nm operating bandwidth for HA5400 EDFA
♦ 500~5000mW (27~37dBm) high output power
♦ 8~64 outputs is optional
♦ Low noise subnumber ( Typ ≤4.5dB, Max ≤5.0dB, Output ≥37dBm )
♦ High performance, high reliability
♦ APC, ACC, ATC controlled selection (HA5400/P)
♦ Powerful RS232 supervisory instruction
♦ Efficient space, flexible installation and easy operation
♦ Excellent P/P ratio
EDFA Parameter
Item |
Unit |
Technical parameter |
|
Bandwidth |
nm |
1545~1565 |
|
Input optical power |
dBm |
-5 ~ +10 |
|
Max output power |
dBm |
40 |
|
Output power stability |
dBm |
±0.5 |
|
Noise |
dB |
≤ 5.0 |
|
Return loss |
Input |
dB |
≥ 45 |
Output |
dB |
≥ 45 |
|
Optical connector |
|
SC/APC&LCAPC |
|
C/N |
dB |
≥ 50 |
|
C/CTB |
dB |
≥ 63 |
|
C/CSO |
dB |
≥ 63 |
|
Supply voltage |
V |
A:AC160V~250V(50Hz);B:DC48V |
|
Consumption |
W |
≤ 90 |
|
Working temperature |
℃ |
-10 - +42 |
|
Max relative humidity |
% |
Max 5% no condensation |
|
Storage temperature |
℃ |
-30 ~ +70 |
|
Devise size |
mm |
464(L)*440(W)*89(H) |
|
Package size |
mm |
640(L)*640(W)*200(H) |
