Specifications and Characteristics of Huawei MA5680t olt List:
|
Model No. |
MA5680T |
MA5683T |
MA5608T |
|
Dimension: |
490*275.8*447.2mm |
442*283.2*263mm |
442*233.5*88mm |
|
Operating Environment |
Temperature: -25℃~+55℃ Humidity:5%~95% (non-condensing) |
Temperature: -40℃~+65℃ Humidity:5%~95% (non-condensing) |
Temperature: -40℃~+65℃ Humidity:5%~95% (non-condensing) |
|
Power Supply Parameters |
-48V DC input Supports dual power protection Working Voltage range -38.4V~-72V |
-48V DC input Supports dual power protection Working Voltage range -38.4V~-72V |
-48V DC input Supports dual power protection Working Voltage range -38.4V~-72V Support 220V / 110V AC input |
|
Backplane Exchange capacity |
3.2Tbit/s |
1.5Tbit/s |
720Gbit/s |
|
Control Board Exchange Capacity |
1920 Gbit/s |
960Gbit/s |
512Gbit/s |
|
Access Capacity |
128*10G EPON 64*10G GPON 128*EPON 256*GPON 768*GE |
48*10G EPON 24*10G GPON 48*EPON 96*GPON 288*GE |
16*10G EPON 8*10G GPON 16*EPON 32*GPON 96*GE |
|
Access Type |
Upstream interface: 10GE optical, GE optical/electricity Business interface: EPON optical port, GPON optical port, 10G EPON optical port, P2P FE optical port, P2P GE optical port, Ethernet optical interface |
||
|
System Performance |
Layer 2 / Layer 3 wire-speed forwarding Support static router /RIP/OSPE.MPLS BITS/E1/STM-1/Ethernet/1588v2/1PPS+ToD clock Maximum support 1:256 splitting ratio Maximum support 60KM |
||
|
Packing |
|
All products are original packing,we can pack the cartons to meet your requirements as the below pictures. |
|
Delivery |
|
Normally,we will ship the goods within 3 working days when received your deposit. We have our own shipping agent who handle with DHL,EMS,FedEx,UPS,TNT,AIR,SEA... |
