Product Details:
|
| Product Name: | GIE4805/2A/500 | Output Voltage: | 48V |
|---|---|---|---|
| Output Frequen: | 50/60Hz | Input Voltage: | 220VAC |
| Output Current: | 10A | Output Power: | >500W |
| Size: | 44.5*482*240mm | Weight: | <12kg |
| Working Temperature:: | -40~+70℃ | Warranty: | 1 Year |
| High Light: | GIE4805S Rectifier Modules,48V 10A Rectifier Modules,GIE4805S |
||
GIE4805S Rectifier Modules 48V 10A Power System 4810 Communication Power
New Emerson GIE4805/2A/500 DC 48V/10A Power System 4810 Communication Power GIE4805S Rack Mount
Descriptions
GIE4805S adopts full bridge soft switching technology, the efficiency is up to 92%. Perfect battery management. With load power-off and battery low voltage protection (LVLD+LVBD) and secondary power-off function, it can realize temperature compensation, automatic float control, automatic voltage regulation, battery capacity calculation, online battery test and other functions. Adopting damage-free hot-swap technology, plug and play, the replacement time is less than 1min.
Specifications
| Output Power | Other |
| Output Type | Single |
| Input Voltage | 220V |
| Output Voltage | 48V |
| Output Current | 0~10A |
| Application | Rectifier module |
| Efficiency | >91% |
| Input voltage range | 90~290VAC |
| Input frequency range | 45~66Hz |
| Size | 44.5*482*240mm |
| Product Keywords | network power,rectifier 48v telecom,gie4805s |
