HuaWei EG8143A5 CATV GPON ONU APC Interface Remote Control

HuaWei EG8143A5 CATV GPON ONU APC Interface Remote Control
HuaWei EG8143A5 CATV GPON ONU APC Interface Remote Control HuaWei EG8143A5 CATV GPON ONU APC Interface Remote Control

Large Image :  HuaWei EG8143A5 CATV GPON ONU APC Interface Remote Control

Product Details:
Place of Origin: China, Guangdong
Brand Name: HuaWei
Model Number: EG8143A5
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable

HuaWei EG8143A5 CATV GPON ONU APC Interface Remote Control

Description
Products Name: GPON ONU Product Model: EG8143A5
Network: WIFI Consumption: <5W
Dimensions (H × W × D): 34 * 175 * 115 Mm Weight: 235g
Maximum Power Consumption: 8.2W Power Adapter Input: 100–240 V AC, 50/60 Hz
High Light:

EG8143A5 CATV GPON ONU

,

EG8143A5 Ftth Gpon Onu

,

EG8143A5

HuaWei EG8143A5 CATV GPON ONU APC Interface Remote Control



HuaWei EG8143A5 CATV RF fiber optic cat APC interface remote control CATV GPON ONU English version



EchoLife EG8143A5 Owerviews

The HW EG8143A5 is a routing-type Optical Network Terminal (ONT) — an integral part of Huawei’s all-optical access solution — that uses Gigabit-capable Passive Optical Network (GPON) technology to implement ultra-broadband access for users. With high forwarding performance ensuring a consistent user experience for voice, data, and High Definition (HD) video services, and future-oriented service support capabilities, EG8143A5 helps enterprises construct the all-optical access solutions deployed on next generation campuses.

EchoLife EG8143A5 Features
1. Smart Services

* Smart Wi-Fi sharing:
Portal/802.1x authentication
SoftGRE-based sharing

2. Smart Interconnection

* Smart Wi-Fi coverage

* Any port any service

* Parental control

* L2/L3 (IPv4) forwarding: 1G uplink, 2G downlink

* SIP/H.248 autonegotiation

3. Intelligent O&M

* eMDI

* Variable-length OMCI messages

* Active/passive rogue ONT detection and isolation

* PPPoE/DHCP simulation testing

* Call simulation, and circuit test and loop-line test

* WLAN simulation




















EchoLife EG8143A5 Specifications

Parameters EchoLife EG8143A5
Dimensions (H x W x D) 34 * 175 * 115 mm
Weight (Without power adapter) Approximately 235 g
Operating Temperature 0–40°C
Operating Humidity 5%–95% RH (non-condensing)
Power Adapter Input 100–240 V AC, 50/60 Hz
UNI 1 x GE, 3 x FE, 1 x POTS, 1 x Wi-Fi (2.4G), and 1 x CATV
NNI 1 x GPON
Maximum Power Consumption* 8.2 W
Maximum PoE Output Power NA
Surge Protection GE port: common mode 4 kV; differential mode 0.5 kV
AC power supply: common mode 6 kV; differential mode 6 kV
Installation Mode Desktop
Compliance Certification CE
GPON Port Connector: SC/APC
Class B+
Receiver sensitivity: –27 dBm
Overload optical power: –8 dBm
Type B single-homing
Type B dual-homing (supported in Layer 2 forwarding)
Ethernet Electrical Port Ethernet port-based VLAN tags and tag removal
1:1 VLAN, N:1 VLAN, or VLAN transmission QinQ VLAN
Limit on the number of learned MAC addresses
MAC address learning
POTS Port Maximum REN: 4
G.711A/μ, G.729a/b, and G.722 encoding/decoding
T.30/T.38/G.711 fax mode
DTMF
Emergency calls (complies with the SIP protocol)
WLAN IEEE 802.11 b/g/n (2.4G)
2 x 2 MIMO
Antenna gain: 2 dBi
WMM
Multiple SSIDs
WPS
Air interface rate: 300 Mbit/s





HuaWei EG8143A5 CATV GPON ONU APC Interface Remote Control 0HuaWei EG8143A5 CATV GPON ONU APC Interface Remote Control 1

HuaWei EG8143A5 CATV GPON ONU APC Interface Remote Control 2







Our service

1. One-to-one "heart-to-heart service".

The sales representative only serves five customers. We look at providing you with continuous long-term service, but not just one or two cooperation.



2. Warranty. 1 year



3. Perfect after-sales service. Specify the phone number 24 hours a day. Mailbox and manager.



4. Quality assurance. 100% new material production, 100% reliable quality.
