Overviews
H3C S5500V2-28F-SI can effectively increase the transmission speed of network clone type data packets, can connect multiple wired devices, can turn off flow control, other ports negotiate to turn on flow control, optimize network applications such as diskless systems, and ensure online games and smooth videos . At the same time, the security control is once again improved to make data transmission more secure; the signal capability is enhanced to make the network speed faster.
Specifications
| Product type | Gigabit Ethernet switch products |
|---|---|
| Application level | Three layers |
| Transmission rate | 10/100/1000Mbps |
| Exchange method | Store-forward |
| Backplane bandwidth | 256Gbps |
| Packet forwarding rate | 69Mpps |
| Number of ports | 36 |
| Port description | 24 100/1000Base-X Gigabit SFP ports, 8 Combo 10/100/1000Base-T adaptive Ethernet ports (and the last 8 SFP ports Combo), 2 Gigabit SFP ports, 2 Gigabit SFP ports SFP+ port |
| Control port | 1 Console port |
| Power supply voltage |
AC: Rated voltage range: 100V~240V, 50/60Hz DC: Input rated voltage range -48V~-60V |
| Power |
AC: 60W DC: 68W |
| Product size | 440×360×43.6mm |
| Product weight | ≤8kg |
| Environmental standards |
Working temperature: 0℃~45℃ Relative humidity: 5%-95% (non-condensing) |
