Product Details:
|
| Model Name: | RB952Ui-5ac2nD (hAP Ac Lite) | Dimensions: | 113 X 89 X 28mm |
|---|---|---|---|
| License Level: | 4 | Size Of RAM: | 64 MB |
| Storage Size: | 16 MB | Product Name: | RB952Ui-5ac2nD (hAP Ac Lite) |
| PoE Out: | Passive PoE | Max Power Consumption: | 8W |
| High Light: | 1000Mbps Fiber Optic Switch,SOHO Gigabit Access Point |
||
Mikrotik RB952Ui-5ac2nD (hAP ac Lite) ROS home dual-band wireless router wifi AP
Descriptions
The hAP ac lite is a Dual-concurrent Access Point, that provides Wifi coverage for 2.4GHz and 5GHz frequencies at the same time.
The device is very small and will look good in any home or office, wall mounting anchor holes are provided.
The hAP ac lite can be powered from the power jack or with passive PoE from a PoE injector. The power adapter is included. Unit provides PoE output function for port 5 – it can power other PoE capable devices with the same voltage as applied to the unit. Maximum load on the port is 500mA.
The hAP ac lite is preconfigured, so all you need to do, is plug in the internet cable, the power, and start using the internet by connecting to the MikroTik network.
Features
• Dual chain wireless 2.4GHz
• Single chain wireless 5GHz
• 650MHz CPU
• 64MB of RAM
• Five x 10/100Mbps Ethernet ports
• Passive PoE output on port 5
• USB port for 3G/4G modem
Specifications
| Details | |
|---|---|
| Product code | RB952Ui-5ac2nD |
| CPU | QCA9531 |
| CPU core count | 1 |
| CPU nominal frequency | 650 MHz |
| Dimensions | 113 x 89 x 28mm |
| License level | 4 |
| Operating System | RouterOS |
| Size of RAM | 64 MB |
| Storage size | 16 MB |
| Storage type | FLASH |
| Tested ambient temperature | -30 + 70 C |
Powering
| Details | |
|---|---|
| Max Power consumption | 8W |
| Number of DC inputs | 1 (DC jack) |
| PoE in | Passive PoE |
| DC jack input Voltage | 10-30 V |
| PoE out | Passive PoE |
Wireless
| Details | |
|---|---|
| Wireless 2.4 GHz number of chains | 2 |
| Wireless 2.4 GHz standards | 802.11b/g/n |
| Antenna gain dBi for 2.4 GHz | 2 |
| Wireless 2.4 GHz chip model | QCA9531 |
| Wireless 5 GHz number of chains | 1 |
| Wireless 5 GHz standards | 802.11ac |
| Antenna gain dBi for 5 GHz | 2 |
| Wireless 5 GHz chip model | QCA-9887 |
Ethernet
| Details | |
|---|---|
| 10/100 Ethernet ports | 5 |
Peripherals
| Details | |
|---|---|
| Number of USB ports | 1 |
| USB Power Reset | Yes |
| USB slot type | USB type A |
Wireless specifications
| 2.4 GHz | |||
|---|---|---|---|
| Transmit (dBm) | Receive Sensitivity | ||
| 1MBit/s | 22 | -96 | |
| 11MBit/s | 22 | -89 | |
| 6MBit/s | 20 | -93 | |
| 54MBit/s | 18 | -74 | |
| MCS0 | 20 | -93 | |
| MCS7 | 16 | -71 | |
| 5 GHz | |||
|---|---|---|---|
| Transmit (dBm) | Receive Sensitivity | ||
| 6MBit/s | 23 | -93 | |
| 54MBit/s | 20 | -75 | |
| MCS0 | 23 | -93 | |
| MCS7 | 19 | -71 | |
| MCS9 | 16 | -63 | |
Ethernet test results
| RB952Ui-5ac2nD | QCA9531 (650Mhz) 100M all port test | ||||||
| Mode | Configuration | 1518 byte | 512 byte | 64 byte | |||
| kpps | Mbps | kpps | Mbps | kpps | Mbps | ||
| Bridging | none (fast path) | 40.6 | 493.0 | 117.4 | 480.9 | 217.0 | 111.1 |
| Bridging | 25 bridge filter rules | 40.6 | 493.0 | 70.1 | 287.1 | 70.9 | 36.3 |
FAQ
1. what's the way to pay?
We support T/T, WESTERN UNION,Paypal
2.What's your shipping way?
Shopped by air sea express
3.What is the product used for packing?
We always use catron, Unless you have different packing needs
With many years of export experience, excellent quality, advanced services and competitive prices, it has won the trust and support of many customers. If you have any questions, please feel free to contact us, we will provide you with quality service.
Our compay have MikroTik products ,If you haven't found the model you want, please contact us.
