MikroTik RB1100x4/RB1100AHx4 13x RB1100ahx2 Gigabit Ethernet ports RouterBOARD Router

MikroTik RB1100x4/RB1100AHx4 13x RB1100ahx2 Gigabit Ethernet ports RouterBOARD Router
MikroTik RB1100x4/RB1100AHx4 13x RB1100ahx2 Gigabit Ethernet ports RouterBOARD Router
MikroTik RB1100x4/RB1100AHx4 13x RB1100ahx2 Gigabit Ethernet ports RouterBOARD Router MikroTik RB1100x4/RB1100AHx4 13x RB1100ahx2 Gigabit Ethernet ports RouterBOARD Router MikroTik RB1100x4/RB1100AHx4 13x RB1100ahx2 Gigabit Ethernet ports RouterBOARD Router MikroTik RB1100x4/RB1100AHx4 13x RB1100ahx2 Gigabit Ethernet ports RouterBOARD Router MikroTik RB1100x4/RB1100AHx4 13x RB1100ahx2 Gigabit Ethernet ports RouterBOARD Router

Large Image :  MikroTik RB1100x4/RB1100AHx4 13x RB1100ahx2 Gigabit Ethernet ports RouterBOARD Router

Product Details:
Place of Origin: China, Guangdong
Brand Name: MikroTik
Certification: FCC,CCC,CE
Model Number: RB1100x4/RB1100AHx4
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable

MikroTik RB1100x4/RB1100AHx4 13x RB1100ahx2 Gigabit Ethernet ports RouterBOARD Router

Description
Product Name: RB1100x4/RB1100AHx4 Architecture: ARM 32bit
Dimensions: 444 X 148 X 47 Mm 2License Level: 6
Operating System: RouterOS Storage Size: 128 MB
Max Power Consumption: 20W Warranty: 1 Year
High Light:

MikroTik Fiber Optic Switch

,

RB1100ahx2 Router

,

RB1100AHx4 Router

MikroTik RB1100x4/RB1100AHx4 13x RB1100ahx2 Gigabit Ethernet ports RouterBOARD Router





The new RB1100AHx4 series of devices uses a new quad core Cortex A15 chip from Annapurna labs, an Amazon company, The chip is clocked at 1.4 GHz, for a maximum throughput of up to 7.5 Gbit.Two models are available, with the RB1100AHx4 Dude edition featuring several high speed storage connectors (two SATA and two M.2) for using a Dude database, proxy cache or any other storage intensive feature. The Dude edition includes a 60 GB M.2 drive already installed.

The devices support IPsec hardware acceleration and are faster at it than any previous RouterBOARD device. The RB1100AHx4 feature two IEC failover power connectors, support 802.3at PoE input and also have a DC telecom power connector for -48 V DC powering.



Specifications

Details
Product code RB1100x4
Architecture ARM 32bit
CPU AL21400
CPU core count 4
CPU nominal frequency 1.4 GHz
Dimensions 444 x 148 x 47 mm
License level 6
Operating System RouterOS
Size of RAM 1 GB
Storage size 128 MB
Storage type NAND
Tested ambient temperature -40°C to 70°C



Details
PoE in 802.3af/at
PoE in input Voltage 20-57 V
Number of AC inputs 2
AC input range 100-240
Number of DC inputs 2 (2-pin terminal, PoE-IN)
2-pin terminal input Voltage -48, 12-57 V
Max power consumption 20 W





Ethernet

Details
10/100/1000 Ethernet ports 13


Peripherals

Details
Memory card type microSD
Memory Cards 1
Serial port RS232







MikroTik RB1100x4/RB1100AHx4 13x RB1100ahx2 Gigabit Ethernet ports RouterBOARD Router 0MikroTik RB1100x4/RB1100AHx4 13x RB1100ahx2 Gigabit Ethernet ports RouterBOARD Router 1MikroTik RB1100x4/RB1100AHx4 13x RB1100ahx2 Gigabit Ethernet ports RouterBOARD Router 2
