Product Details:
|
Product Name: | RB4011iGS+RM | Max. LAN Data Rate: | 1000Mbps |
---|---|---|---|
WAN Ports: | 2 | Number Of DC Inputs:: | 2 (DC Jack, PoE-IN) |
PoE In: | Passive PoE | CPU: | AL21400 |
Architecture: | ARM 32bit | Storage Size: | 512 MB |
High Light: | 10g SFP+ Gigabit Wired Router,AL21400 Gigabit Wired Router,MikroTik RB4011iGS+RM |
Original MikroTik RB4011iGS+RM 11 port 10g SFP + quad core Gigabit wired router 1U rack
Overviews
RB4011 series - amazingly powerful routers with ten Gigabit ports, SFP+ 10Gbps interface and IPsec hardware acceleration for a great price!
The RB4011 uses a quad core Cortex A15 CPU, same as in our carrier grade RB1100AHx4 unit. The unit is equipped with 1GB of RAM, can
provide PoE output on port #10 and comes with a compact and professional looking solid metal enclosure in matte black.
RB4011iGS+RM (Ethernet model) includes two rackmount ears that will securely fasten the unit in a standard 1U rack space.
Note: The RB4011 does not support Passive DAC modules and SFP GPON modules.
Powerful 10xGigabit port router with a Quad-core 1.4Ghz CPU, 1GB RAM, SFP+ 10Gbps cage and desktop case with rack ears
Specification
Details | |
---|---|
Product code | RB4011iGS+RM |
Architecture | ARM 32bit |
CPU | AL21400 |
CPU core count | 4 |
CPU nominal frequency | 1400 MHz |
Dimensions | 228 x 120 x 30 mm |
License level | 5 |
Operating System | RouterOS |
Size of RAM | 1 GB |
Storage size | 512 MB |
Storage type | NAND |
Tested ambient temperature | -40°C to 70°C |
Details | |
---|---|
PoE in | Passive PoE |
PoE in input Voltage | 18-57 V |
PoE out | Passive PoE up to 57V |
PoE-out ports | Ether10 |
Number of DC inputs | 2 (PoE-IN, DC jack) |
DC jack input Voltage | 12-57 V |
Max out per port output (input > 30 V) | 400 mA |
Max out per port output (input < 30 V) | 600 mA |
Max total out (A) | 600 mA |
Max power consumption | 33 W |
Max power consumption without attachments | 18 W |
Details | |
---|---|
10/100/1000 Ethernet ports | 10 |
Details | |
---|---|
SFP+ ports | 1 |
Details | |
---|---|
Serial port | RJ45 |
Details | |
---|---|
PCB temperature monitor | Yes |
Voltage Monitor | Yes |
