Features
1. Enterprise-class features
The EdgeSwitch series switches offer a rich set of advanced switching features and Layer 2 protocols, as well as Layer 3 routing functionality.
2. Fiber optic connection
The EdgeSwitch series of switches has ports for fiber optic connectivity. The 24-port models are equipped with two SFP ports providing bandwidth up to 1 Gbps.
3. Advanced user interface
EdgeSwitch is designed with manageability in mind, allowing administrators to configure and monitor the switch functions in the graphical user interface. For advanced users, there is a standard command line interface (CLI), accessible via the serial console port, telnet and SSH networks.
4. EdgeSwitch - Features
• MSTP / RSTP / STP
• VLAN, Private VLAN, Voice VLAN
• Link Aggregation
• DHCP Snooping, IGMP Snooping
• TACACS +, RADIUS, 802.1X, MAC Filtering, ACL DiffServ, CoS
• Static Routing
• DHCP server functionality
Specifications
Features / filters | |
Number of LAN ports | 24x [10/100/1000M (RJ45)] |
PoE ports quantity | 24x [802.3af/at (1G)] |
LAN standard | Gigabit Ethernet 10/100/1000 Mb/s |
Power (W) | 250 |
Housing type | Rack (1U), Desktop, |
Switching layer | 3, 2, |
Management | CLI - Command Line Interface, Via a web browser, |
Basic technical parameters | |
Dimensions | 485 × 43,7 × 285,4 mm (19,09 × 1,72 × 11,24 cala) |
Weight | 4.7 kg (10.4 lb) |
Total speed without line blocking | 26 Gbps |
Energy consumption | 250 W |
Power method | 100-240 V AC / 50-60 HzUniversal input |
Power | AC / DC, internal, 250 W DC |
Network interfaces | (24) 10/100/1000 Mbps RJ45 Ethernet Ethernet ports(2) 1 Gbps Ethernet SFP ports |
Management interface | (1) RJ45 serial portEthernet I / O band |
Installation in a rack cabinet | Yes, 1U high |
ESD / EMP protection | Air ± 24 kV, contact ± 24 kV |
Shock and Vibration | ETSI300-019-1.4 standard |
Working temperature | -5 ° C to 40 ° C |
Working humidity | 5% to 95% |
Certificates | CE, FCC, IC |
PoE to the port | |
PoE interfaces | POE + IEEE 802.3af / at (pins 1, 2+; 3, 6-)24 V DC passive PoE (pins 4, 5+; 7, 8-) |
Maximum PoE + power per port via PSE | 34.2 W |
802.3at mode voltage range | 50-57V |
Maximum passive PoE power per port | 17W |
24V passive voltage range PoE | 20-27 V |
FAQ
1. what's the way to pay?
We support T/T, WESTERN UNION,Paypal
2. What's your shipping way?
Shopped by air sea express
3. What is the product used for packing?
We always use catron, Unless you have different packing needs
