Large Image :  CAP Ac RBcAPGi-5acD2nD Gigabit Dual Frequency Wireless Ceiling AP CAP Lite

Product Details:
Place of Origin: China, Guangdong
Brand Name: Mikrotik
Model Number: cAP ac/RBcAPGi-5acD2nD
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable

CAP Ac RBcAPGi-5acD2nD Gigabit Dual Frequency Wireless Ceiling AP CAP Lite

Description
Product Name: CAP Ac/RBcAPGi-5acD2nD Architecture: ARM 32bit
CPU: IPQ-4018 CPU Core Count: 4
License Level: 4 Size Of RAM: 128MB
CPU Nominal Frequency: 716 MHz Warranty: 1 Year
High Light:

mikrotik cap ac

,

mikrotik cap ac lite

,

RBcAPGi-5acD2nD

CAP Ac RBcAPGi-5acD2nD Gigabit Dual Frequency Wireless Ceiling AP CAP Lite



Descriptions

The cAP ac is a very capable and powerful wireless access point that looks beautiful on both walls and ceilings. The concurrent dual band wireless radio supports dual chain 2 GHz 802.11b/g/n and 5 GHz in a/n/ac standards, and will provide coverage in 360 degrees around it.

Even though the radio supports repeater mode, the two Ethernet ports give you the ability to extend your network with cables, even if PoE power is required, since the cAP ac supports 802.3af/at PoE input on the first port, and passive PoE output on the second port. Device supports IPsec hardware acceleration too.

* cAP ac (International) supports 2412-2484MHz and 5150MHz-5875MHz range (Specific frequency range can be limited by country regulations).



* cAP ac-US (USA) is factory locked for 2412-2462MHz, 5170-5250MHz and 5725-5835MHz frequencies. This lock can not be removed.

Specifications

Details
Product code RBcAPGi-5acD2nD
Architecture ARM 32bit
CPU IPQ-4018
CPU core count 4
CPU nominal frequency 716 MHz
Dimensions Round case:136 mm, height: 30 mm; Square case: 145 mm x 145 mm x 30 mm
License level 4
Operating System RouterOS
Size of RAM 128 MB
Storage size 16 MB
Storage type FLASH
Tested ambient temperature -40°C to 50°C


Wireless capabilities

Details
Wireless 2.4 GHz Max data rate 300 Mbit/s
Wireless 2.4 GHz number of chains 2
Wireless 2.4 GHz standards 802.11b/g/n
Antenna gain dBi for 2.4 GHz 2
Wireless 2.4 GHz chip model IPQ-4018
Wireless 2.4 GHz generation Wi-Fi 4
Wireless 5 GHz Max data rate 867 Mbit/s
Wireless 5 GHz number of chains 2
Wireless 5 GHz standards 802.11a/n/ac
Antenna gain dBi for 5 GHz 2.5
Wireless 5 GHz chip model IPQ-4018
Wireless 5 GHz generation Wi-Fi 5
AC speed AC1200


Ethernet

Details
10/100/1000 Ethernet ports 2


Powering

Details
Number of DC inputs 1 (PoE-IN)
Max power consumption 24 W
Max power consumption without attachments 13 W
FAN count Passive
PoE in 802.3af/at
PoE in input Voltage 17-57 V


PoE-out

Details
PoE-out ports Ether2
PoE out Passive PoE up to 57V
Max out per port output (input < 30 V) 500 mA
Max out per port output (input > 30 V) 400 mA
Max total out (A) 500 mA
Network expandability
In case the radio supports repeater mode, the two Ethernet ports offer the possibility of extending the network with cables even if PoE power is required, as cAP ac supports 802.3af / at PoE input on the first port and passive PoE output on the second port. The device also supports IPsec hardware acceleration.

CAP ac frequency range
The MikroTik cAP ac (international) wireless access point supports the range 2412-2484 MHz and 5150-5875 MHz. The specific frequency range may be limited by national regulations.


Main features:
• Working temperature from -40 ° C to 50 ° C
• 2.4 GHz and 5 GHz wireless network
• Number of processor cores 4







CAP Ac RBcAPGi-5acD2nD Gigabit Dual Frequency Wireless Ceiling AP CAP Lite 0CAP Ac RBcAPGi-5acD2nD Gigabit Dual Frequency Wireless Ceiling AP CAP Lite 1
