Overviews
H3C S5560S-SI Series High Performance Ethernet Switch
H3C S5560S-SI switch is the second-generation standard three-layer Gigabit Ethernet switch product independently developed by New H3C Technology Co., Ltd. (hereinafter referred to as H3C). It is designed for high performance, high port density, high uplink speed and easy installation. The second-generation intelligent network management switch designed for the best network environment.
H3C S5560S-SI series switch host solidifies 4-port 10 Gigabit/4 Gigabit uplink ports. While realizing high-density Gigabit access, it can provide users with cost-effective 10 Gigabit/Gigabit uplink capabilities and protect user investment. At the same time, the H3C S5560-SI series switches support IRF2 intelligent elastic architecture, which can stack 9 devices to form a logical entity, so that the device capacity can be smoothly expanded according to the network development, providing users with extremely high flexibility and flexibility in network configuration. Expansion capabilities.
Specifications:
| Product type | Gigabit Ethernet switch, enterprise switch |
|---|---|
| Application level | Three layers |
| Transmission rate | 10/100/1000Mbps |
| Exchange method | store-forward |
| Backplane bandwidth | 336Gbps/3.36Tbps |
| Packet forwarding rate | 132Mpps |
| MAC address table |
Support black hole MAC address, support to set the maximum number of port MAC address learning |
| Port structure | non-modular |
| Number of ports | 52 |
| Port description | 48 10/100/1000TX ports, 4 SFP portsControl port 1 console port |
| Stacking function | can be stacked |
| VLAN | supports port-based VLAN, QinQ, Voice VLAN, protocol VLAN, and MAC VLAN |
| QOS |
Supports packet filtering, supports SP/WRR/SP+WRR queue scheduling, supports two-way ACL, supports port-based rate limiting, supports flow-based redirection, and supports time periods |
| Network management |
Support command line interface (CLI) configuration, support Telnet remote configuration, support configuration through the console port, support SNMP (EImple Network Management Protocol), support RMON (Remote Monitoring) alarms, events, history records, support iMC network management system, support WEB network management, support system log, support hierarchical alarm, support IRF, support NTP |
| Security management |
Support user hierarchical management and password protection, support SSH2.0, support port isolation, support 802.1X, support port security, support MAC address authentication, support IP Source Guard, support HTTPs, support EAD |
| Power supply |
Minimum: AC: 18W Maximum: AC: 41W |
| Product size | 440×230×43.6mm |
| Product weight | <3.5kg |
| Environmental standards |
Working environment temperature: 0℃~45℃ Relative humidity of working environment (non-condensing): 10%~90% |
