122.3W Wireless Access Controller 20Gbps Forwarding capability

122.3W Wireless Access Controller 20Gbps Forwarding capability
122.3W Wireless Access Controller 20Gbps Forwarding capability 122.3W Wireless Access Controller 20Gbps Forwarding capability 122.3W Wireless Access Controller 20Gbps Forwarding capability

Large Image :  122.3W Wireless Access Controller 20Gbps Forwarding capability

Product Details:
Place of Origin: Guangdong, China
Brand Name: Huawei
Certification: FCC, CE, ROHS
Model Number: AirEngine 9700-M
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable

122.3W Wireless Access Controller 20Gbps Forwarding capability

Description
Products Name: AirEngine 9700-M Port: 16 X GE + 12 X 10 GE + 2 X 40 GE
Forwarding Capability: 20Gbps Weight: 5.65KG
Dimensions: 43.6*442*420mm Power Consumption: 122.3W
Maximum Number Of Managed APs: 2048 Warranty: 1 Year
High Light:

122.3W Wireless Access Controller

,

20Gbps Wireless Access Controller

,

122.3W Wireless Access Point Controller

122.3W Wireless Access Controller 20Gbps Forwarding Capability



AirEngine 9700-M HuaWei Enterprise Wireless Access Controller can manage up to 2048 APs



Descriptions

AirEngine 9700-M access controller

AirEngine 9700-M is a wireless access controller (Access controller) launched by Huawei for medium and large enterprise campuses, enterprise branches and campuses. It can manage up to 2048 APs and has a forwarding capacity of up to 120Gbps. With Huawei's full range of 802.11ac/802.11ax wireless access points, application environments such as medium and large campus networks, corporate office networks, wireless metropolitan area networks, and hotspot coverage can be established.



Features



1. High capacity, high performance

Support 16 GE ports, 12 10GE ports and 2 40G ports, provide 120Gbps forwarding capability, and manage 2048 APs



2. Flexible use

Flexible data forwarding method, supporting direct forwarding and tunnel forwarding; Flexible user permission control, providing access control strategy control capabilities based on users and roles



3. 138 network operation mode

Rich network operation and maintenance methods Rich network operation and maintenance methods, which can be maintained through the network management eSight, WEB network management, and command line (CLI)



Technical specifications

Product overview
Parameter AirEngine 9700-M
MANAGE THE NUMBER OF APS 2048
Product size 43.6*442*420mm
Product weight 5.65kg
Forwarding capability

120Gbps (direct orwarding)

60Gbps (tunnel forwarding)


Other parameters

Local account:4096

Number of access control lists: 32768

Number of ARP table items:65536

Number of multicast table items: 2048

Number of VLANs: 4096

Mac address table number:65536

Relative humidity: 5% RH-95%RH (non-condensation)

Operating temperature: 0-45 degrees C

Interface 2 40G optical ports (of which 1 40G and 4 10G mutually exclusive), 12 10GE optical ports, 16 GE ports, 1 ETH management interface, 1 Console interface, 1 USB 2.0, forwarding capacity of up to 120Gbps
Power supply AC POWER IS SUPPORTED, HOT-SWAP IS SUPPORTED, AND HOT BACKUP IS SUPPORTED
Power consumption 122.3W
HOW THE AP AND AC ARE NETWORKED SUPPORTS L2/L3 LAYER NETWORK TOPOLOGY
Forward mode Direct forwarding/tunnel forwarding is supported
AC REDUNDANT BACKUPS SUPPORTS A BACKUP METHOD OF 1-1 HOT/N1
Wireless protocol 802.11 a/b/g/n/ac/ac wave2/ax



122.3W Wireless Access Controller 20Gbps Forwarding capability 0122.3W Wireless Access Controller 20Gbps Forwarding capability 1


FAQ



1. what's the way to pay?

We support T/T, WESTERN UNION,Paypal



2.What's your shipping way?

Shopped by air sea express



3.What is the product used for packing?

We always use catron, Unless you have different packing needs
