Product Details:
|
| Brand Name: | UBNT | Model Number: | RBSEXTANTG-5PHnD(SEXTANT G) |
|---|---|---|---|
| RouterOS License: | 3 | CPU Core Count: | 600 MHz |
| Dimensions: | Ø250mm, Height 90mm, 830g | Max. Power Consumption: | 13.8W |
| Storage Size: | 64MB | PoE In Input Voltage: | 10-28 V |
| Warranty: | 1 Year | ||
| High Light: | RBSEXTANTG-5PHnD,18dBi 5GHz antenna,5ghz wifi antenna |
||
Mikrotik RBSEXTANTG-5PHnD(SEXTANT G) 18dBi 5GHz 13.8W wireless access antenna
Overviews
The SEXTANT is a 18dBi 5GHz antenna with a built in RB911G router. It has two polarizations to give you all benefits of 2×2 MIMO in 802.11n.
Inside is the high power RB911 dual chain wireless device, with high performance, high output power, and a Gigabit Ethernet port, to fully
utilize the benefit of 802.11n high speed wireless.
Easy to use and quick to deploy, SEXTANT is ideal for point to point links.
Package contains SEXTANTG5PHnD, mounting kit, PoE injector, power adapter
Features
* RBSEXTANTG5HPnD-US (USA) is factory locked for 5170-5250MHz and 5725-5835MHz frequencies. This lock can not be removed.
* RBSEXTANTG5HPnD (International) supports 5150MHz-5875MHz range (Specific frequency range can be limited by country regulations).
Specifications
| Details | |
|---|---|
| Product code | RBSEXTANTG-5HPnD |
| Architecture | MIPSBE |
| CPU | AR9342 |
| CPU core count | 1 |
| CPU nominal frequency | 600 MHz |
| Dimensions | Ø250mm, height 90mm, 830g |
| RouterOS license | 3 |
| Operating System | RouterOS |
| Size of RAM | 64 MB |
| Storage size | 64 MB |
| Storage type | NAND |
| MTBF | Approximately 200’000 hours at 25C |
| Tested ambient temperature | -40°C to 70°C |
| Details | |
|---|---|
| Number of DC inputs | 1 (PoE-IN) |
| Max power consumption | 13.8 W |
| FAN count | Passive |
| PoE in | Passive PoE |
| PoE in input Voltage | 10-28 V |
| Details | |
|---|---|
| Wireless 5 GHz Max data rate | 300 Mbit/s |
| Wireless 5 GHz number of chains | 2 |
| Wireless 5 GHz standards | 802.11a/n |
| Antenna gain dBi for 5 GHz | 18 |
| Wireless 5 GHz chip model | AR9342 |
| Wireless 5 GHz generation | Wi-Fi 4 |
| Details | |
|---|---|
| 10/100/1000 Ethernet ports | 1 |
| Details | |
|---|---|
| Certification | CE, FCC, IC, EAC, ROHS |
| 5 GHz | Transmit (dBm) | Receive Sensitivity |
|---|---|---|
| 6MBit/s | 30 | -96 |
| 54MBit/s | 27 | -80 |
| MCS0 | 30 | -96 |
| MCS7 | 24 | -80 |
