High performance Gigabit service processing capacity
It adopts the industry's advanced network dedicated dual core CPU, combined with the advanced software and hardware technology of H3C company, and provides Gigabit business concurrent processing ability and excellent network experience Number of NAT sessions: 250000 Recommended carrying capacity: 250-350
Multi Wan load balancing
By default, all LAN ports can be switched to WAN interface Support a variety of WAN link load sharing modes: Based on operator destination address, WAN link bandwidth, policy based routing, etc; Built in carrier address library, at the same time, it provides one click download of the latest carrier address library on the official website, which is easy to operate
Fine flow control
Refined application identification and control, supporting the identification and control of nearly 1000 kinds of common PC and mobile phone applications, such as Im applications, streaming media applications, stock financing applications, game applications, P2P applications, and filtering and speed limiting of the identified application traffic Support HTTP protocol URL filtering, website black and white list, keyword fuzzy matching
Rich means of network security
Support local wechat authentication, portal authentication and other access control functions
Diversified firewall functions
Comprehensive built-in anti attack means: support various ARP anti attack, single packet attack, scanning attack, flooding attack and other preventive means IP based network traffic speed limiting mechanism and NAT table entry limiting mechanism
Built in AC
Built in AC function, supporting unified management, configuration and upgrade of H3C mini series wireless AP
Specifications
attribute | MER5200 |
Carrying capacity | 250-350 |
Applicable bandwidth | 1Gbps |
IPSec encryption performance | 400Mbps |
Number of IPSec VPN tunnels | 128 |
Number of NAT sessions | 250 thousand |
Manageable number of mini APS | 300 |
CON | 1 |
Micro SD card slot | 1 |
USB2.0 | 1 |
WAN Ethernet port | 2GE(1Combo) |
LAN Ethernet port | 4GE (all can be switched to WAN) |
Maximum power consumption | 20W |
AC power supply |
Rated range: 100~240V 50/60Hz |
Overall dimension (w × D × h, mm) | 440*225*44 |
ambient temperature | 0~45℃ |
Ambient relative humidity | 5~95% (no condensation) |
