Product Details:
|
| Model Number: | RBDisc-5nD | CPU Nominal Frequency: | 600 MHz |
|---|---|---|---|
| Size Of RAM: | 64 MB | Supported Input Voltage: | 11 V - 30 V |
| Max Power Consumption: | 6W | PStorage Size: | 16 MB |
| Dimensions: | 265mm, Height: 80mm | Warranty: | 1 Year |
| High Light: | 8km Wireless Network Bridge,Height 80mm Wireless Network Bridge,5.8G Wireless Ethernet Bridge |
||
MMikrotik DISC Lite5 RBDisc-5nD 5.8G 300 million wireless bridge 5-8km
Description: Mikrotik DISC Lite5
Mikrotik is glad to introduce a new high gain 5GHz CPE with disruptive pricing!
t’s DISC Lite5, based on our popular LHG hardware design. DISC Lite5 is equipped with 21dBi Dual Chain 802.11n integrated CPE with 600MHz CPU, 64MB RAM, 1x 10/100Mbps Ethernet port and RouterOS L3 installed. It comes complete with a power supply, PoE injector and mounting kit.
This DISC Lite5 (International) supports 5150MHz-5875MHz range.
On the DISC Lite5 there is directly a holding device for the Quickmount Pro (QMP), which can be added optionally. The QMP provides better alignment to the target, especially when it comes to compensating for differences in altitude.
Content of delivery:
Technical details:
| Product code | RBDisc-5nD |
| CPU nominal frequency | 600 MHz |
| CPU core count | 1 |
| Size of RAM | 64 MB |
| 10/100 Ethernet ports | 1 |
| Wireless chip model | AR9344 |
| Wireless standards | 802.11a/n |
| Supported input voltage | 11 V - 30 V |
| PoE in | Yes |
| Dimensions | 265mm, height: 80mm |
| Operating System | RouterOS |
| Tested ambient temperature | -40°C .. +70°C |
| License level | 3 |
| Antenna gain DBI | 21 |
| CPU | AR9344 |
| Max Power consumption | 6W |
| Number of chains | 2 |
| Storage type | FLASH |
| Storage size | 16 MB |
Wireless details:
| 5 GHz | |||
|---|---|---|---|
| Transmit power (dBm) | Receive Sensitivity | Transmit power (mW) | |
| 6MBit/s | 25 | -96 | 316 |
| 54MBit/s | 20 | -80 | 100 |
| MCS0 | 25 | -96 | 316 |
| MCS7 | 19 | -75 | 79 |
Wireless parameters may be limited in software, depending on your local regulatory limitations
Ethernet details:
| RBDisc-5nD | AR9344 (600MHz) 100M 1 port test | ||||||
| Mode | Configuration | 1518 byte | 512 byte | 64 byte | |||
| kpps | Mbps | kpps | Mbps | kpps | Mbps | ||
| Bridging | none (fast path) | 8.1 | 98.4 | 23.5 | 96.3 | 182.5 | 93.4 |
| Bridging | 25 bridge filter rules | 8.1 | 98.4 | 23.5 | 96.3 | 87.6 | 44.9 |
| Routing | none (fast path) | 8.1 | 98.4 | 23.5 | 96.3 | 182.5 | 93.4 |
| Routing | 25 simple queues | 8.1 | 98.4 | 23.5 | 96.3 | 106.6 | 54.6 |
| Routing | 25 ip filter rules | 8.1 | 98.4 | 23.5 | 96.3 | 60.5 | 31.0 |
