Product Details:
|
| Product Name: | CE6870-48T6CQ-E | FProduct Type: | Data Center Switch |
|---|---|---|---|
| Port Description: | Downstream Port: 48x10GE SFP Plus Upstream Port: 6x40GE QSFP28 | The Supply Voltage: | AC:90-290V DC:-38.4V--72V |
| Power Supply Power: | 287W | Product Size: | 442*420*43.6mm |
| Product Weight: | 7.6kg | Warranty: | 1Year |
| High Light: | CE6857-48S6CQ-EI,QSFP28 Agile Switch,HuaWei 48 Gigabit Optical Agile Switch |
||
CE6857-48S6CQ-EI HuaWei 48 Gigabit optical + 6x40/100GE QSFP28 agile switch
|
device family |
device subgaces |
device model |
abbreviation |
supported versions |
|---|---|---|---|---|
| CE6800 | CE6857 | CE6857-48S6CQ-NO | CE6857EI |
V200R005C10~V200R019C10 illustrate:
AMONG THEM, V200R005C20 VERSION IS NOT SUPPORTED. |
power slot
CloudEngine 6800 Series switches contain two power slots that allow the installation of pluggable power modules. Users can use a single-supply module or a dual-power module to power the switch, and the use of dual-power module power supply provides greater reliability for the switch.
fan slots
CloudEngine 6800 Series switches provide four fan module slots for system stability and thermal quality by installing pluggable fan modules for forced cooling.
when the switch is in normal use, it is recommended that four fan modules be in place at the same time. the fan module supports hot backup, after the failure of the single fan module, the system supports normal operation in the short term, but it is recommended to replace the faulty fan module immediately.
all fan modules are hot-swappable.
Depending on the power module and fan module using different air ducts, the cooling air ducts of CloudEngine 6800 Series switches can be divided into front and rear air ducts or rear front air ducts.
CE6857-48S6CQ-EI does not have a management network port indicator, the service interface indicator is 10GE, 40/100GE interface indicator, and the remaining panel indicators are similar to CE6865-48S8CQ-EI, which is exemplified here with CE6865-48S8CQ-EI.
10GE SFP+ ETHERNET OPTICAL INTERFACE
|
attribute |
description |
|---|---|
| connector type | LC |
| optical interface properties | determined by the module or cable selected |
| complies with standards | IEEE802.3ae |
| working mode |
1000Mbit/s, 10Gbit/s adaptive full-duplex mode |
40GE/100GE QSFP28 PACKAGE OPTICAL INTERFACE
|
attribute |
description |
|---|---|
| connector type | the connector type of the fiber optic is determined by the optical transceiver |
| optical interface properties | determined by the module or cable selected |
| complies with standards | IEEE802.3ba |
| working mode | full-duplex mode |
Console interface
|
attribute |
description |
|---|---|
| connector type | RJ45 |
| complies with standards | RS232 |
| working mode | Duplex UART(Universal Asynchronous Receiver/Transmitter) |
| baud rate |
9600bit/s～115200bit/s the default is 9600bit/s |
ETH MANAGEMENT INTERFACE (RJ45)
|
attribute |
description |
|---|---|
| connector type | RJ45 |
| complies with standards | IEEE802.3ab |
| working mode |
10/100/1000Mbit/s adaptive full-duplex mode |
| maximum effective distance | 100m |
USB PORT
THE USB INTERFACE CAN BE CONNECTED TO A U DISK FOR LOG BACKUP, SYSTEM SOFTWARE BACKUP AND UPLOAD, AND SUPPORTS THE U DISK OPENING FUNCTION.
|
specification |
description |
|
|---|---|---|
| physical parameters |
|
|
| environment parameters | temperature |
|
| relative humidity | 5% RH TO 95% RH, NON-CONDENSING. | |
| altitude | ＜5000m | |
| NOISE (SOUND PRESSURE, ROOM TEMPERATURE 27°C) |
|
|
| power parameters | the type of power input | ac/dc |
| ac input characteristics |
|
|
| dc input characteristics |
|
|
| hvdc input characteristics | not supported | |
| rated input current |
|
|
| the power consumption of the whole machine | maximum power consumption | 287W |
| typical power consumption |
152W (100% LOAD, 48-PORT SFP+ HIGH-SPEED CABLE AND 6-PORT QSFP28 HIGH-SPEED CABLE, DUAL POWER SUPPLY) 195W (100% LOAD, FULL PORT STUB LIGHT MODULE, AMBIENT, DUAL POWER SUPPLY) |
|
| heat consumption of the whole machine | maximum heat consumption | 979BTU/Hr |
| typical heat consumption |
519BTU/hr (100% load, 48-port SFP+ high-speed cable and 6-port QSFP28 high-speed cable, dual power supply) 665BTU/hr (100% load, full short-range optical module with ports, dual power supplies) |
|
| lightning protection specifications |
power protection:
|
|
| cooling | heat dissipation | wind cooling dissipates heat |
| cooling air ducts | front, rear or rear front air ducts, depending on the fan module and power supply module selected. | |
| reliability and availability | power module backup | support 1+1 backup. |
| fan module backup | support 3+1 backup, fan module support hot backup, after the failure of a single fan module, the system supports normal operation in the short term, but it is recommended to replace the faulty fan module immediately. | |
| hot-swappable | power supply modules and fan modules are hot-swappable. | |
| MTBF (YEARS) | 45.3 | |
| MTTR AVERAGE REPAIR TIME (HOURS) | 1.68 | |
| usability | 0.99999576002 | |
| technical specifications | processor | 4 core, 1.4GHz. |
| DRAM Memory | 4GB | |
| NOR Flash | 64MB | |
| NAND Flash | 2GB | |
| stack | interfaces that support service port stacking | 10GE OPTICAL PORT, 40GE OPTICAL PORT AND 100GE OPTICAL PORT. |
| product certification |
|
|
