Overviews
With the rapid development of network information technology, small and medium-sized enterprises deeply feel the huge market space brought by e-commerce and the convenience and efficiency brought by informatized office to small and medium-sized enterprises. More and more small and medium-sized enterprises are starting to build or expand. While owning the office network, it also puts forward some requirements for the characteristics of network equipment, which are mainly reflected in the following aspects:
* Network function requirements. On the basis of high bandwidth, performance and reliability, egress gateway equipment pays more attention to the management and control of egress traffic, thereby improving the office efficiency of employees and the utilization of limited egress bandwidth.
* Network security requirements. With the increasing popularity of BYOD (Bring your own devices), network security boundaries have been broken, and customers have put forward higher requirements for the security of network devices, and network access authentication has become an important means to protect corporate information security.
* Network management requirements. Customers need simpler and more automated management methods to simplify the configuration, change, management and maintenance of network equipment and bearer applications, and to automate the deployment and management of network equipment to improve efficiency and reduce management costs.
Faced with such opportunities and challenges, H3C has developed the MSR830-WiNet series of next-generation smart gateway routers based on more than ten years of in-depth understanding of the network and solid technology accumulation. The MSR830-WiNet series routers are mainly suitable for application environments such as the office network outlets of small and medium-sized enterprises and institutions and branch offices of large and medium-sized enterprises. This product can provide an integrated comprehensive solution for the enterprise network within the smallest investment range, fully meet the needs of diversified applications such as future business expansion and management, and conform to the current status and trend of enterprise IT construction.
Hardware specifications
The basic parameters | |
---|---|
Product model |
MSR830-5BEI-WiNet
|
The type of product |
Enterprise routers
|
The port structure |
1 USB 2.0
|
WAN interface |
2
|
LAN interface |
3
|
Software parameters | |
---|---|
Package forwarding rate |
200Kpps
|
firewall |
Yes
|
Other performance |
Nat sessions: 250,000
Encryption Performance: 40Mbps Firewall Performance: 900Mbps |
Other parameters | |
---|---|
size |
440×225×44mm
|
power supply |
100-240V,50/60Hz
|
power |
500
|
The working environment |
0-40C
5%-95% (no condensation) |
