Product Details:
|
| Model Number: | SSN1SXCSA | Optical Type Supported: | 100Gbps CFP Optical Module |
|---|---|---|---|
| Working Mode: | Full-duplex | Dimensions (H X W X D): | 37.2 Mm X 178.7 Mm X 193.3 Mm (1.46 In. X 7.04 In. X 7.61 In.) |
| Typical Power Consumption: | 51.0 W | Weight: | 1.3 Kg (2.87 Lb) |
| Compliant Standard: | IEEE 802.3 | Warranty: | 1 Year |
| High Light: | HuaWei OSN3500 business board,SSN1SXCSA Optical Interface Board,Full Duplex Optical interface board |
||
HuaWei OSN3500 business board SSN1SXCSA super cross clock SXCSA
Overviews
Transmitter series is a practical, high index, multifunctional and short distance transmission products, is the construction of CATV HFC network equipment.
This machine adopts the high linearity, low chirp DFB laser as light source, RF drive part adopts advanced predistortion compensation and closed loop AGC,APC, ATC control, to ensure that the excellent performance, and make the optical receiver output level is constant, various working parameters by the micro processing control, optional SNMP network management software and 1+1 power supply backup, chassis temperature can achieve the automatic control, can be applied to high-end users.
Specifications
| Parameter | Unit | Index |
| Working wavelength | nm | 1550±10 |
| Side mode suppression ratio | dB | ≥45(SMSR) |
| Extinction ratio | dB | ≥20 |
| Noise equivalent intensity | dB/Hz | ≤-160 |
| Output power | mW | 2-30 |
| Reflection loss | dB | ≥55 |
| Fiber connector | FC/APC or SC/APC | |
| Working bandwidth | MHz | 47~862 |
| Input level | dBμV | 80±5(AGC) |
| Flatness | dB | ≤±0.75(47~862MHz) |
| Reflection loss | dB | >16 |
| AGC control range | dB | ±10 |
| MGC control range | dB | ±10 |
| Input impedance | Ω | 75 |
| Test channel | PAL-D/60CH,NTSC/80CH | |
| CNR | dB | ≥51 |
| Network management interface | RJ45(SNMP), RS232 Or RS485 | |
| Power supply | V | 90~265VAC or -48VDC |
| Power consumption | W | 20 |
FAQ
1. what's the way to pay?
We support T/T, WESTERN UNION,Paypal
2.What's your shipping way?
Shopped by air sea express
3. What is the product used for packing?
We always use catron, Unless you have different packing needs
Our service
1. 100% tested before delivery;
2. Payment: T/T
3. Lead time: within 5-8 days after payment;
4. Samples can be available within 3-5 working day;
5. Shipping freight is quoted under your requests;
6. Your inquiry related to our products or prices will be replied in 24hour
