Product Details:
Place of Origin: Guangdong, China
Brand Name: H3C
Certification: FCC,CE,CCC
Model Number: EWP-WA6320-C-FIT
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable

Wireless AP Access Point H3C EWP-WA6320-C-FIT Indoor Dual Band High Rate

Description
Model Number:: EWP-WA6320-C-FIT Power Input: PoE Power Supply: Meets The 802.3at Power Over Ethernet Standard
Dimensions (l×w X H): 220mm × 220mm × 100mm Maximum Power Consumption: 18W
Antenna Type: Built-in Directional Antenna Maximum Rate: 1.267Gbps
MIMO: SPATIAL STREAM: 2×2:2 Maximum Transmit Power: 2.4G: 27dBm (combined Power) 5G: 26dBm (combined Power)
High Light:

1.267Gbps Wireless AP access point

,

18W Wireless AP access point

,

Builtin antenna Wireless Access Point

H3C EWP-WA6320-C-FIT indoor dual-band high-rate wireless AP access point



Overviews

H3C WA6320-C wireless product is a new generation of 802.11ax AP product independently developed by H3C Technology Co., Ltd. (H3C). It adopts the whole machine dual-band four-stream 802.11ax design and can be widely used in enterprises, schools and medical scenarios.

WA6320-C has a built-in smart antenna, supports dual-band access, compact and beautiful appearance, flexible installation methods, suitable for wall-mounted, ceiling-mounted and other installation methods.



Specifications

key performance
frequency range 802.11ax/ac/n/a : 5.725GHz-5.850GHz (China); 5.47 GHz~5.725GHz; 5.15 GHz~5.35GHz (China)
802.11ax/b/g/n : 2.4GHz-2.483GHz (China)
modulation mode 11b:DSS:CCK@5.5/11Mbps,DQPSK@2Mbps,DBPSK@1Mbps
11a/g:OFDM:64QAM@48/54Mbps,16QAM@24Mbps,QPSK@12/18Mbps,BPSK@6/9Mbps
11n:MIMO-OFDM:BPSK,QPSK,16QAM, 64QAM
11ac:MIMO-OFDM:BPSK,QPSK,16QAM,64QAM,256QAM
11ax: MIMO-OFDM: BPSK,QPSK,16QAM,64QAM,256QAM,1024QAM
network interface ETHERNET INTERFACE: 1 X 10/100/1000M PORT

antenna
antenna type built-in smart antenna system

other parameters
status led Blink alternate blinking mode, yellow,green and blue different working state blinking mode, terminal access breath flashing mode
power supply mode Supports 802.3at AF power supply; supports 54V DC
power supply power ≤ 16.5W (EXCLUDING PSE AND USB)
product size 185x185x33mm
product weight 0.423Kg
environmental standards Working temperature / storage temperature: -10oC ~ 55oC / - 40oC ~ 70oC
operating humidity / storage humidity: 5% ~ 95% (non-condensing)
other properties Console port: 1
Built-in Internet of Things: Built-in Bluetooth 5.0
modulation technology: OFDM : BPSK@6/9Mbps, QPSK@12/18Mbps, 16-QAM@24Mbps, 64-QAM@48/54Mbps
DSSS : DBPSK@1Mbps, DQPSK@2Mbps, CCK@5.5/ 11Mbps
MIMO-OFDM (11n): MCS 0-15
MIMO-OFDM (11ac): MCS 0-9
MIMO-OFDM (11ax): MCS 0-11
Transmit Power: 20dBm
Adjustable Power Granularity: 1dBm
Reset/ Factory Reset: Support
Safety Specifications: GB4943, EN60601-1-2 (Medical), UL/CSA 60950-1, IEC/EN 60950-1, IEC/EN 62368-1
EMC: GB9254, EN301 489, EN55022, FCC Part 15, RSS-210
RF Certification: FCC Part 15, EN 300 328, EN 301 893, MIIT Radio Transmitting Equipment Type Approval
Health: FCC Bulletin OET-65C, EN 50385, IC Safety Code 6
MTBF: >850000H
protection class IP41



Wireless AP Access Point H3C EWP-WA6320-C-FIT Indoor Dual Band High Rate 0Wireless AP Access Point H3C EWP-WA6320-C-FIT Indoor Dual Band High Rate 1
