Product Details:
|
Product Name: | TP4860C-D07A2 | Input Voltage: | 220-240V AC |
---|---|---|---|
Output Power: | 700W | Output Current:: | 60A |
Output Voltage:: | 48V | Weight: | ≤32kg (without Modules And Batteries) |
Size(W × D × H): | 450mm (wide, Excluding Air Outlet Protruding Part) ×300mm (deep) ×630mm (high) | Warranty: | 1 Year |
High Light: | HuaWei TP4860C-D07A2 Rectifier Modules,TP4860C Switching Power Supply Cabinet,Switching Power Supply Cabinet |
HuaWei TP4860C-D07A2 outdoor wall-mounted communication switching power supply cabinet TP4860C 48V 60A
HuaWei TP4860C outdoor wall-mounted power cabinet HuaWei TP4860C product features:
The system is compatible with 870W, 1000W, 1600W rectifier modules
1. Rectifier module efficiency point>96%
2. Intelligent battery management and battery protection to extend battery life
3. Support battery anti-reverse connection design, effectively avoid the danger of safety and equipment damage caused by battery reverse connection
4. Support site environment monitoring, remote management can be achieved through dry contacts and secure serial ports
5. The LCD display of the monitoring module realizes visual monitoring HW TP4860C outdoor wall-mounted power supply cabinet
HW TP4860C6. Built-in inverter can be used to provide uninterrupted power supply for both DC and AC loads.
7. The cabinet design is compact and small in size, and supports multiple installation methods such as wall hanging, landing, and pole holding.
8. Outdoor wall-mounted power supply IP55 high-grade protection, low noise, strong environmental adaptability
220V/110V dual live wire AC input voltage is converted to -48V voltage, system output current is 60A, 20AH, 40AH lead-acid batteries can be built-in, 220V AC output can be supported through the inverter module, monitoring and backup functions are provided, and wall-mounted batteries can be configured The cabinet realizes 80AH backup power; it supports multiple installation methods such as wall hanging, pole holding and landing. It has the characteristics of compact design, high efficiency and energy saving, and flexible power backup.
HuaWei WALL-MOUNTED COMMUNICATION POWER SUPPLY 48V60A WALL-MOUNTED COMMUNICATION POWER SUPPLY HW TP4860C WALL-MOUNTED COMMUNICATION POWER SUPPLY PRODUCT SPECIFICATIONS
Model | TP4860C | |||
---|---|---|---|---|
System parameters | Size | 450mm (wide, excluding air outlet protruding part) ×300mm (deep) ×630mm (high) | ||
Weight | ≤32kg (without modules and batteries) | |||
Rated capacity | 30A/60A (COMPATIBLE WITH 15A AND 30A MODULES), 700WAC (OPTIONAL INVERTER) | |||
Cooling mode | Straight ventilation | |||
How to maintain it | Pre-maintenance, support module-level replacement | |||
The way to go | The bottom of the cabinet is wired | |||
How to install it | Wall hanging, holding rod or floor mounting | |||
Protection level | IP55 | |||
Bbattery (optional) | Built-in 1 set of 40AH lithium batteries; or a built-in set of 20Ah/40Ah lead-acid batteries; Two sets of 40AH batteries can be paralleled by adding a battery cabinet; | |||
Environmental metrics | Run the ambient temperature | -40℃~+45℃ | ||
Operating ambient humidity | 5% to 95% (no condensation) | |||
Elevation | 0 to 4000m (altitude in the range of 2000 to 4000m, 1c lower for each 200m temperature increase) | |||
Ac power distribution | Exchange input | Single-phase three-wire (L, N, PE) or 110V dual-fire (L1, L2, PE) (AC configuration can only support single-phase 220V, 50Hz grid) | ||
Inverter output (optional) | 1000VA/700W, 3×10A/1P | |||
Ac input voltage | 85 TO 300VAC, RATING: 220VAC | |||
The frequency of ac inputs | 45 to 66Hz, rated: 50Hz/60Hz | |||
Ac input lightning protection | 20/40kA (8/20?s) | |||
Dc lightning protection | Poor mode 10kA, common mode 20kA | |||
The signal port is mine-proof | Poor mode 3kA, common mode 5kA | |||
Dc power distribution | The output voltage | -42 TO -58VDC, DEFAULT: -53.5VDC | ||
The output power | 4800W | |||
Battery branch | 1×63A/1P IS AVAILABLE | |||
DC LOAD BLVD | 3×16A/1P IS AVAILABLE | |||
Rectifier module | Efficiency | >96% | ||
Enter the voltage | 85 TO 300VAC, RATING: 220VAC | |||
Monitoring unit | Sensor interface | Door magnetism, flooding, smoke, battery temperature, ambient temperature and humidity | ||
Digital input | 4 way | |||
Alarm output | 4 way | |||
The communication interface | RS485/RS232 | |||
Battery (optional) | Rated capacity | 20Ah lead-acid battery | 40Ah lead-acid battery | 40Ah lithium battery |
Weight | 6.35kg×4 | 14.6Kg×4 | 25kg | |
Nominal voltage | 12V | 12V | 48V |
