Emerson 5800W 100A R48-5800a/R48-5800e DC Power Rectifier Module

Emerson 5800W 100A R48-5800a/R48-5800e DC Power Rectifier Module
Emerson 5800W 100A R48-5800a/R48-5800e DC Power Rectifier Module Emerson 5800W 100A R48-5800a/R48-5800e DC Power Rectifier Module Emerson 5800W 100A R48-5800a/R48-5800e DC Power Rectifier Module Emerson 5800W 100A R48-5800a/R48-5800e DC Power Rectifier Module

Large Image :  Emerson 5800W 100A R48-5800a/R48-5800e DC Power Rectifier Module

Product Details:
Place of Origin: China, Guangdong
Brand Name: Emerson
Certification: CE RoHS FCC
Model Number: R48-5800a/R48-5800e
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Delivery Time: 5-8days

Emerson 5800W 100A R48-5800a/R48-5800e DC Power Rectifier Module

Output Power: >500W Output Type: Single
Output Voltage: 36V Output Current: 120A
Product Name: R48-5800E Switching Power Supply Application: FTTH FTTB FTTX Network
Single Package Size : 85X15X45 Cm Single Gross Weight: 10.000 Kg
High Light:

5800W Switched Mode Power Supply





Emerson R48-5800a/R48-5800e DC Power Rectifier module 5800W 100A power supply

R48-5800E Emerson 48V 5800E High Efficiency Telecom Rectifier
1. High Efficiency, near 97%
2. Hot pluggable-facilitates
R48-5800e Emerson 48V 5800W High Efficiency Telecom Rectifier


The eSure™ R48-5800e rectifier converts 260 to 530 VAC 3-phase supply voltages into stable nominal -48V DC voltage adjustable to the needs of the application. The R48-5800E is a constant power rectifier designed with the latest patented switchmode technology using DSP (Digital Signaling Processor) functionality for efficient operation.

For a higher load capacity, rectifiers can be connected in parallel and intelligent control can be added with the help of a separate controller.

Overview of Emerson R48-5800A

R48-5800a Emerson communication power supply rectifier module, nominal output voltage 48v, nominal output current 100a


Emerson R48-5800A communication power supply product features:

* Ultra-wide AC input voltage working range

* Large system input capacity

* Adopt comprehensive soft switch patented technology and sleep energy-saving patent, high efficiency and energy saving

* Advanced electromagnetic compatibility design, in line with ce, nebs, and other domestic and foreign standards

* No damage hot swap technology, plug and play, replacement time is less than 1min

* Complete fault protection and fault alarm function

* AC power distribution cabinets and DC power distribution cabinets are equipped with independent monitoring units, which can be used independently from the system


Emerson R48-3500E rectifier module use environment

Environmental conditions

Working temperature: -5℃~45℃, derating use above 45℃

Storage temperature: -40℃~70℃

Relative humidity: ≤95%RH, no condensation

Altitude: ≤2000m (above 2000m requires derating to use)

Cooling method: forced air cooling

Input characteristics Input voltage range: 85Vac~290Vac, single-phase three-wire system Rated input voltage: 200Vac~250Vac Power derating input voltage range: 85Vac~176VA Do not work withstand static voltage: 415Vac Rated input current: <16A@2900W Input current: <19A@2900W/176Vac Input impulse current: <30A Allowable input grid frequency: 45~65Hz Rated input grid frequency: 50Hz/60Hz
Output characteristics Output DC voltage range: 42V~58V Output DC current: 0A~60.5A Voltage stabilization accuracy ≤±0.5% Load regulation rate ≤±0.5% Voltage adjustment rate ≤±0.1% Boot upshoot amplitude ≤±1%
Output current limiting characteristics Stepless current limit, current limit point 0A~60.5A, can be adjusted by monitoring module, current limit accuracy:≤±1.5A (42V~58V)
Power factor and THD

Power factor ≥0.90 @25%~50% rated output power Power factor ≥0.98 @50%~rated output power Power factor ≥0.99 @rated output power

THD≤5% @50%~rated output power

efficiency The rated efficiency is greater than 91%, and the efficiency reaches 92%.
Current sharing The current sharing error of the module is within ±1.5A.
Temperature coefficient (1/℃) ≤±0.01%
Dynamic Response When the load changes step by step 50%-25%-50% or 50%-75%-50%, the response time is less than or equal to 200ms, and the overshoot is less than or equal to 5%.
Start Time

The power-on mode can be selected through the monitoring module:

1) Normal boot mode

The time delay from AC power-on to module output is less than 5 seconds. 2) The output starts slowly

This function is set by the external monitoring module to be effective, the startup time can be set by the monitoring module, the range can be set from 8s to 128s, and the accuracy is ≤±10%.


Emerson 5800W 100A R48-5800a/R48-5800e DC Power Rectifier Module 0


1. what's the way to pay?

We support T/T, WESTERN UNION,Paypal

2.What's your shipping way?

Shopped by air sea express

3.What is the product used for packing?

We always use catron, Unless you have different packing needs
