AP4050DN-HD Indoor Dual Band Wireless LAN Access Point

Large Image : AP4050DN-HD Indoor Dual Band Wireless LAN Access Point

Product Details:

Place of Origin:	Guangdong, China
Brand Name:	Huawei
Model Number:	AP4050DN-HD, AP4050DN-HD

Payment & Shipping Terms:

Minimum Order Quantity:	Negotiable
Price:	Negotiable

Contact Now

AP4050DN-HD Indoor Dual Band Wireless LAN Access Point

Description

Type:	Optical Fibers	Use:	FTTX
Antenna Type:	Built-in High-density Smart Antennas	Maximum Transmit Power:	2.4 GHz: 22 DBm (combined Power) 5 GHz: 22 DBm (combined Po
Radio Protocols:	802.11a/b/g/n/ac/ac Wave2	Operating Temperature:	Re: -10°C To 50°C
MIMO Spatial Streams:	2 X 2:2 MU/SU-MIMO	Dimensions (H X W X D):	65 Mm X 240 Mm X 334 Mm
Warranty:	1 Year	Selling Units:	Single Item
Single Package Size :	57X5X32 Cm	Single Gross Weight:	3.000 Kg
Package Type:	New In The Box.
High Light:	Huawei AP4050DN-HD , AP4050DN-HD Access Point , 802.11a Access Point

Original Huawei AP4050DN-HD indoor dual band wireless LAN access point with built-in intelligent high-density antenna

AP4050DN-HD Access Point — Huawei products

AP4050DN-HD Access Point

Huawei AP4050DN-HD is a wireless access point that supports 802.11ac Wave 2, 2 x 2 MIMO, and two spatial streams. The AP4050DN-HD provides a rate of up to 1.267 Gbit/s. It uses built-in high-density smart antennas and is applicable to indoor high-density stadiums.

Huawei AP4030TN is a wireless access point in compliance with 802.11ac standards. It supports Software-Defined Radio (SDR) and uses a triple-radio frequency design with each radio frequency supporting 2 x 2 MIMO and two spatial streams. The AP4030TN provides a rate of up to 2.6 Gbit/s and is applicable to environments such as eClassroom, high-density venues, shopping malls, and supermarkets.Embedded smart antennas, purpose-built for high-density scenarios, reduce construction costs and mitigate interference between APs

Dual Ethernet interfaces support link aggregation and traffic load balancing to ensure link reliability
PoE OUT is supported, saving costs in switch ports by 50%
Cloud-based AP management using the Agile Controller-Cloud Manager

AP4050DN-HD Basic specifications
Item	Description
Physical specifications	Dimensions (H x W x D)	65 mm x 334 mm x 240 mm
	Weight	1.5 kg
	System memory	* 256 MB DDR3L * 64 MB NOR FLASH
Power specifications	Power input	* DC: 12 V ± 10% * PoE power supply: in compliance with IEEE 802.3af/at
	Maximum power consumption	* 11.8 W (in 802.3af PoE or DC mode) * 13.9 W (in 802.3at PoE mode, excluding the output power of the PoE_OUT port) NOTE:The actual maximum power consumption depends on local laws and regulations.
Environment specifications	Operating temperature	* -60 m to +1800 m: -10°C to +50°C * 1800 m to 5000 m: Temperature decreases by 1°C every time the altitude increases 300 m.
	Storage temperature	-40°C to +70°C
	Operating humidity	5% to 95% (non-condensing)
	IP rating	IP41
	Atmospheric pressure	53 kPa to 106 kPa

AP4050DN-HD Radio specifications
Item	Description
Antenna type	Built-in dual-band directional antenna (beamwidth: 30 degrees)
Antenna gain	* 2.4 GHz: 13 dBi * 5 GHz: 10 dBi
Maximum number of users	Fit AP: ≤ 512 Fat AP: ≤ 512 Cloud AP: ≤ 512 NOTE:The actual number of users varies according to the environment.
Maximum number of VAPs for each radio	16
Maximum transmit power	* 2.4 GHz: 22 dBm (combined power) * 5 GHz: 22 dBm (combined power) NOTE:The actual transmit power depends on local laws and regulations.
Maximum number of non-overlapping channels	2.4 GHz (2.412 GHz to 2.472 GHz) * 802.11b/g * 20 MHz: 3 * 802.11n * 20 MHz: 3 * 40 MHz: 1	5 GHz (5.18 GHz to 5.825 GHz) * 802.11a * 20 MHz: 13 * 802.11n * 20 MHz: 13 * 40 MHz: 6 * 802.11ac * 20 MHz: 13 * 40 MHz: 6 * 80 MHz: 3	NOTE:The table uses the number of non-overlapping channels supported by China as an example. The number of non-overlapping channels varies in different countries. For details, see the Country Codes & Channels Compliance. NOTICE:If the AP is delivered to the USA, pay attention to the following on channel and frequency band usage: 1. The country code of the AP is fixed. 2. High power radars working at frequencies in the range of 5.25 GHz to 5.35 GHz, 5.47 GHz to 5.6 GHz, and 5.65 GHz to 5.725 GHz can interfere with or even damage APs working at the same frequency.
Channel rate supported	* 802.11b: 1, 2, 5.5, and 11 Mbit/s * 802.11a/g: 6, 9, 12, 18, 24, 36, 48, and 54 Mbit/s * 802.11n: 6.5 to 400 Mbit/s * 802.11ac Wave 2: 6.5 to 867 Mbit/s
