Product Details:
|
| Model Number: | CFP-100G-SR10 | Encapsulation: | CFP |
|---|---|---|---|
| Interface Standards: | 100GBASE-SR10 | The Connector Type: | MPO/PC (24-core, Cross Type B, Female) |
| The Fiber Type: | MMF | Center Wavelength (nm): | 850nm |
| Transfer Rate (bit/s): | 100 Gbit/s | Warranty: | 1 Year |
| High Light: | HuaWei Multimode Optical Module,CFP-100G-SR10 Multimode Optical Module,100G Multimode Fiber Module |
||
HuaWei High Speed Optical Module CFP-100G-SR10 100G Multimode Module 850nm 10*10G 0.1km
CFP-100G-SR10 indicator
| Project | The indicator value |
|---|---|
| Basic information | |
| The name of the module | CFP-100G-SR10 |
| Part code | 02310YTB |
| Model | CFP-100G-SR10 |
| Encapsulation | CFP |
| Interface standards | 100GBASE-SR10 |
| The connector type | MPO/PC (24-core, cross type B, female) |
| The fiber type | MMF |
| Working shell temperature | 0°C~70°C |
| Transfer rate (bit/s) | 100 Gbit/s |
| Target Transfer Distance (km) |
Multimode fiber (OM2): 0.03km Multimode fiber (OM3): 0.1km Multimode fiber (OM4): 0.15km |
| Send end light parameters | |
| Center Wavelength (nm) | 850nm |
| Maximum transmit optical power (dBm) | 2.4dBm |
| Minimum sending optical power (dBm) | -7.6dBm |
| Minimum extinction ratio (dB) | 3dB |
| The receiver light parameter | |
| Receive Sensitivity (dBm) | -5.4dBm |
| Overloaded optical power (dBm) | 2.4dBm |
|
illustrate:
Supports 1 min 2 x 40GE and 1 min 10 x 10GE.
|
|
