Service Requirement | Features and Benefits |
High performance |
|
High reliability |
|
Easy O&M |
|
Service convergence |
|
Security |
|
SD-WAN Ready |
|
Specifications
System Parameters | |
Processor | 16-core |
Forwarding Performance (LAN - > WAN + WAN - > LAN, NAT + ACL + QoS, IMIX) |
SRU-400H: 10 Gbps SRU-600H: 12 Gbps |
IPsec performance (IMIX) |
SRU-400H: 6 Gbps SRU-600H: 7.5 Gbps |
Fixed WAN ports | SRU-400H: WAN: 14*10GE SFP+(compatible with GE SFP) +10*GE RJ45 (All WAN ports can be configured as LAN) SRU-600H: WAN: 14*10GE SFP+(compatible with GE SFP) +10*GE RJ45 (All WAN ports can be configured as LAN) |
Fixed LAN ports | - |
SIC slots | 4 |
WSIC slots | 2 (default)/4 (maximum) |
XSIC slots | 2 (default)/4 (maximum) |
USB port | 1*USB2.0 |
Auxiliary or console port | 1 x RJ45 console port |
Memory |
SRU-400H: 8 GB SRU-600H: 16 GB |
Flash memory |
SRU-400H: 2 GB SRU-600H: 4 GB |
Hot swapping | Supported |
Dimensions and Weight | |
Router dimensions, With no mounting bracket installed (H x W x D) | 88.1 mm x 442 mm x 470 mm |
Router dimensions, With mounting bracket installed (H x W x D) | 88.1 mm x 482.6 mm x 470 mm |
Packaging dimensions (H x W x D) | 160 mm x 570 mm x 725 mm |
Weight | 8.85 kg |
Rack | IEC |
Occupied rack space | 2U |
Power Specifications, Power Consumption, and Heat Dissipation | |
Rated input voltage range (AC) | 100 V to 240 V |
Rated input frequency (AC) | 50 Hz/60 Hz |
Maximum input voltage range (AC) | 90 V to 264 V |
Maximum input current (AC) | 5 A |
Maximum output power (AC) | 350 W |
Power supply redundancy | Hot-swappable dual power supplies |
Typical power consumption | 80 W |
Maximum power consumption | 160 W |
Fan module | Independent pluggable fan modules |
Airflow | Left to right |
Noise leve | 54.2 dB |
Environment Parameters | |
Operating temperature | 0ºC to 45ºC |
Operating humidity | 5% to 95% (noncondensing) |
Operating altitude | < 5000 m (16404.2 ft.) |
Storage temperature | –40ºC to +70ºC |
Storage altitude | < 5000 m (16404.2 ft.) |
